Radio Information

Appendix B Radio Information

B.1 RF LTE Specifications
The LTE equipment model with the MC7304 module provides LTE, DC-HSPA+, HSPA+, HSDPA, HSUPA, WCDMA,
GSM, GPRS, EDGE network connectivity over several radio frequency bands, in accordance with 3GPP Standards.
This product is supplied with YWX-6221SAX9-508 antennas. To comply with the regulations in force, do not pick oth-
er antennas.
Technology: LTE
Bands
Band 3
Band 7
Band 20
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+
Bands
Band 1
Band 8
Technology: GSM / GPRS / EDGE
Bands
EGSM 900 (900 MHz)
DCS 1800 (1800 MHz)
B.2 RF GSM/WCDMA Specifications
The GSM/WCDMA equipment model with the MC8705 module provides WCDMA, GSM, GPRS, EDGE network con-
nectivity over several radio frequency bands, in accordance with 3GPP Standards.
This product is supplied with YWX-6221SAX9-508 antennas. To comply with the regulations in force, do not pick oth-
er antennas.
Technology: UMTS(WCDMA)
34
Frequencies
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
Tx: 832–862 MHz
Rx: 791–821 MHz
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Frequencies
Tx: 880–915 MHz
Rx: 925–960 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Radiated Transmit Power
+21 dBm ± 1 dBm
+20 dBm ± 1 dBm
+21 dBm ± 1 dBm
Radiated Transmit Power
+21 dBm ± 1 dBm
+21 dBm ± 1 dBm
Radiated Transmit Power
+30 dBm ± 1 dBm
+28 dBm ± 1 dBm
