4.
Mount the switcher to the rack support, using the two included rack screws.
IR
1
2
Figure 23.
Furniture Mounting
To mount an SW2 DP switcher under a desk, table, or podium, use the optional MBU 123
Mini Under-Desk Mounting Kit as follows:
1.
If rubber feet were previously attached to the bottom of the unit, remove them.
2.
Remove the two screws from each side of the switcher. Retain the screws for possible
reassembly later.
3.
Attach the brackets to the sides of the unit, using the provided machine screws.
Figure 24.
4.
Hold the unit with the attached brackets against the underside of the table or other
furniture. On the mounting surface, mark the location of the screw holes for each
bracket.
3
IN
P U
4
T S
5
6
7
8
1
2
3
O U
T P
4
U T
S
5
6
7
8
EN
TE
R
PR
ES
ET
M A
AV
V S
M AT
E R
R IX
I/O
IE S
SW
VI D
IT C
H ER
AU
+d
D
B
-d
B
AU
D IO
SE
TU
P
Mounting an SW2 DP to a Back of the Rack Support
Preparing the SW2 DP Switcher for Under-furniture Mounting
SW2 DP • Reference Information
