Enabling Front Panel Lockout (Executive Mode)
Front panel lock mode (executive mode) disables all front panel controls. Putting the
switcher in this mode enhances security by protecting against inappropriate or accidental
changes to settings. When the switcher is in lock mode, RS-232 and auto-input switching
remain available.
To lock or unlock the front panel, press and hold Input buttons 1 and 2 simultaneously for
3 seconds, then release them. The front panel LEDs blink three times, indicating that front
panel lock mode has been enabled or disabled (see the illustration below).
Press and hold simultaneously
for 3 seconds.
Figure 10.
You can also lock the front panel by using SIS commands (see the
(Executive Mode)
Resetting
The following types of reset are available for the SW2 DP:
Factory settings
To reset the switcher to its original factory settings:
1.
2.
3.
Retain current firmware
To reset the switcher to its default settings while retaining the currently installed firmware
version:
1.
2.
You can also perform this reset by using an SIS command (see the
page 20).
1
2
Enabling or Disabling Front Panel Lock Mode
commands on page 19).
Disconnect power from the unit if it is connected.
Press and hold the Input 1 button while connecting power to the unit.
Continue holding the Input 1 button until the power-up sequence completes.
Press and hold the Input 1 button. The unit performs the power-up self-test, in which all
front panel LEDs blink once in succession.
When the self-test completes (after approximately 6 seconds all LEDs go dark except
the one for the most recently selected input), release the button.
Release buttons.
LEDs blink 3 times.
Front Panel Lockout
Reset
command on
SW2 DP • Operation
