9.2

PCI Configuration Space Map

Table 35 PCI Configuration Space Map
Bus Number (hex)
00h
00h
00h
00h (see Note 2)
00h (see Note 4)
00h (see Note 1)
00h (see Note 1)
00h (see Note 1)
00h (see Note 1)
00h (see Note 1)
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
01h (see Note 3)
02h (see Note 3)
03h (see Note 3)
04h (see Note 3)
05h
06h
06h
06h
06h
06h
07h (see Note 3)
08h (see Note 3)
09h (see Note 3)
Copyright © 2018 congatec AG
Device Number (hex) Function Number (hex) Device ID
00h 00h
00h 02h
01h 00h
01h 01h
01h 02h
01h 03h
01h 04h
01h 05h
01h 06h
01h 07h
08h 00h
08h 01h
08h 02h
14h 00h
14h 03h
18h 00h
18h 01h
18h 02h
18h 03h
18h 04h
18h 05h
18h 06h
18h 07h
00h 00h
00h 00h
00h 00h
00h 00h
00h 00h
01h 00h
02h 00h
03h 00h
04h 00h
05h 00h
00h 00h
00h 00h
00h 00h
Description and Device ID
0x15D0 Root Complex
0x15D1 IOMMU
0x1452 PCIe Dummy Host Bridge
0x15D3 PCIe PEG Bridge 0
0x15D3 PCIe PEG Bridge 1
0x15D3 PCIe GPP Bridge 0
0x15D3 PCIe GPP Bridge 1
0x15D3 PCIe GPP Bridge 2
0x15D3 PCIe GPP Bridge 3
0x15D3 PCIe GPP Bridge 4
0x1452 PCIe Dummy Host Bridge
0x15DB Internal PCIe GPP Bridge 0 to Bus A
0x15DC
Internal PCIe GPP Bridge 0 to Bus B
0x790B SMBus Controller
0x790E
LPC Bridge
0x15E8 Data Fabric
0x15E9 Data Fabric
0x15EA Data Fabric
0x15EB
Data Fabric
0x15EC
Data Fabric
0x15ED Data Fabric
0x15EE
Data Fabric
0x15EF Data Fabric
PCI Express Port 0
PCI Express Port 1
PCI Express Port 2
PCI Express Port 3
0x2608
PCI Express Switch
0x2608 PCI Express Switch port 0
0x2608
PCI Express Switch port 1
0x2608
PCI Express Switch port 2
0x2608
PCI Express Switch port 3
0x2608
PCI Express Switch port 4
PCI Express Port 4
PCI Express Port 5
PCI Express Port 6
