Chapter 8 - Meeting Rooms List
8-4
Table 8-1 lists the icons used to describe the various Meeting Room types and
their status.
Table 8-1: Meeting Room Types and Icons
Icon
(green)
(green)
(gray)
(gray)
Description
Meeting Rooms - A category in the MCU tree that lists the
Meeting Rooms defined in the system.
Active Meeting Room - Video A video Meeting Room that
was activated when the first participants or chairperson
connected to it.
Active Meeting Room - Audio An Audio Only Meeting
Room that was activated when the first participants or
chairperson connected to it.
Passive Meeting Room - Video A video Meeting Room
that is in a passive mode, waiting to be activated. This
Meeting Room uses both Audio and Video media.
Passive Meeting Room - Audio An Audio Only Meeting
Room that is in a passive mode, waiting to be activated.
