Storage
Temperature
Operating Humidity
Altitude
MTBF
Noise
Weight
Dimensions
(W x D x H)
The weight only includes that of the empty chassis and fans. The whole device's weight is subject to that of
the modules selected.
The RG-N18014 switch is an A-class product and may cause radio disturbance to surroundings. In this case,
users are advised to take proper measures against the disturbance.

Product Appearance

The hardware system of the RG-N18014 switch is composed of the chassis, the power system, modules and the cooling
system.
 The power system provides eight power supply slots and supports N+M power supply redundancy. Users are
recommended to configure redundancy for the power supplies.
The RG-N18014 switch provides two supervisor module slots, 12 service module slots and four switch fabric module

slots. The supervisor modules support 1+1 redundancy. Users are recommended to configure redundancy for the
supervisor modules. Users may choose different service modules as needed.
 The cooling system is composed of the fan trays and air filters. Fan trays are at the back of the chassis. The air filters
of the service module and the supervisor module are on a side of the chassis. The air filter of the switch fabric
module is on the front of the chassis.
Figure 0-1 Appearance of the RG-N18014 Switch
-40 to 70°C
10%-90% RH (non-condensing)
Long term operation height: 3000m at 50℃. The temperature decreases by 1℃ as the altitude
ranging from 3000m to 4000m increases by each 200m.
Operation height: 4000m max
Storage height: 4000m max
216,000 hours
72.9 dB at 35℃
82.7 dB at 50℃
Net weight: 107.55 kg (including the chassis and fans)
442 mm x 776 mm x 886.2 mm (cable management brackets excluded), 20U
442 mm x 814 mm x 886.2 mm (cable management brackets included), 20U
