Primary/standby supervisor
module LED
Fault alarm LED
SD card slot status LED
FE module status LED
Fan status LED
Power status LED
DCMI port status LED
MGMT port status LED
Specifications
Model
CPU
BOOTROM
Flash Memory
SDRAM
External Port
Button
Power Consumption
Hot Swapping
Management
Redundancy
EMC Standards
Safety Standards
Operating
Solid green
Off
Primary
Solid green
Off
Solid red
Alarm
Solid yellow
Off
None
Solid green
Blinking green
Off
FE
Solid red
Blinking green
Solid green
FAN
Solid yellow
Solid red
PWR Off
Solid green
Solid red
None Off
Green
Yellow
Blinking
None Off
Green
Yellow
Blinking
M18010-CM
Quad-core CPU, each core with the clock speed of 1.0G
8 MB
512 MB
DDRIII 4 GB
One Console port;
One 10/100/1000M MGMT port;
One DCMI port;
One SD card slot;
One USB port
One Reset button
<40W
Supported
Supported
GB9254-2008 CLASS A
GB4943-2011
0 to 50°C
errors.
The module is operational
The module acts as the standby supervisor module.
The module acts as the primary supervisor module.
No fault
The system fails, interrupting functioning of the whole
system or a module; the device may be damaged if it
continues operating.
The device overheats, which will affect the system
performance. The system may continue operating.
SD card is not installed, or is not connected.
An SD card is loaded.
Data is being accessed from and written into an SD card
The module is NOT receiving power or is NOT in the
position.
The module is faulty.
Initialization is in progress. Continuous blinking indicates
errors.
The fan is operational.
The fan is NOT in the position.
The fan is faulty.
The power supply module is NOT in the position.
The power supply module is operational.
The power supply module is faulty.
The DCMI port is NOT connected.
The DCMI port is connected at 1000Mbps.
The DCMI port is connected at 10/100Mbps.
The DCMI port is transmitting or receiving data.
The MGMT port is NOT connected.
The MGMT port is connected at 1000Mbps.
The MGMT port is connected at 10/100Mbps.
The MGMT port is transmitting or receiving data.
