Connecting IR Sensors to VSX 8000 Systems

Powering On

Powering On the VSX 3000 or VSX 3000A Desktop System

The VSX 8000 system provides a connector for an external IR sensor. Refer to
your system's setup sheet for connection details.
The VSX 8000 system is compatible with the following IR sensors:
• Xantech® 480-00
• Xantech 490-90
• Xantech 780-80
• Xantech 780-90
The VSX 8000 system is not compatible with the external IR sensor for the
VS4000™ system.
Connect power and power on the system after you have connected the rest of
the equipment that you will use with it.
The VSX 3000, VSX 3000A, VSX 5000, VSX 6000, and VSX 6000A systems have
external power supplies.
The VSX 7000 and VSX 7000s systems come with a separate subwoofer. Power
to the system is supplied through the subwoofer.
Do not use any power supply other than the one supplied with your VSX system.
Using the wrong power supply will void the warranty and may damage your system.
The VSX 3000 and VSX 3000A systems have three power switches.
To power on the VSX 3000 or VSX 3000A:
1. Press the power switch near the connectors on the back of the system.
2. Press the power switch on the lower back corner of the monitor.
3. Press the power button on the front of the monitor.
Setting Up Your System Hardware
2 - 33
