Rack Mechanical Drawing and Dimensions
3.25" x 19.125" x 8.5" (82.55mm x 485.78mm x 215.9mm)
Fig. 14
Fig. 14a
Fig. 14b
Fig. 14c
(ON)
3-Wire
Line Cord
Removable Terminal
Block
Rear
Terminal
Legend
3.125"
79.4mm
(
)
Bottom
17.625"
447.7mm
8.5"
215.9mm
Front
19.125"
485.8mm
0.75"
19.1mm
Maximal Rack Access Power Controllers (Fused)
