Introduction

51&AVRprog is little and powerful portable programmer for
MCS51 series and Atmel AVR microcontrollers. 51&AVRprog
enables also programming serial EEPROM with interface types
IIC (24Cxx), Microwire (93Cxx) and SPI (25Cxx). The
programmer is equipped by DIL ZIF 40pin socket. The quality
of programmer is completed by comfortable control program.
51&AVRprog interfaces with the IBM PC 486 compatible or
higher, portable or desktop personal computers. A programmer
allows you to directly connect to your PC through any standard
parallel (printer) port - no special interface card is needed.
51&AVRprog programmer is driven by an easy-to-use control
program with pull-down menu, hot keys and on-line help.
Selecting of device is performed by its class, by manufacturer
or simply by typing a fragment of vendor name and/or part
number.
Standard device-related commands (read, blank check,
program, verify, erase) are boosted by some test functions
(signature-byte
(autoincrement).
All known data formats are supported. Automatic file format
detection and conversion during load of file.
The rich-featured autoincrement function enables to assign
individual serial numbers to each programmed device - or
simply increments a serial number, or the function enables to
read serial numbers or any programmed device identification
signatures from a file.
The 51&AVRprog can make for use of DIL to PLCC and SOIC
socket converters.
Warning: Jumper must be in position JP2-JP3 for MCS51
devices and JP3-JP4 for AVR family device. Jumper is
accessible after removing bottom part of programmer case.
Default jumper position is JP2-JP3 (for MCS51 family).
Connecting 51&AVRprog
programmer to PC
Switch off the PC and programmer. Insert the connection
cable, included in the 51&AVRprog programmer delivery, to
the free printer port of PC. If your computer is equipped with
check), and
87
some special
51&AVRprog
functions
