Problems related to the PREPROM-02aLV
PC interconnection, and their removing
If you have any problems with PREPROM-02aLV
interconnection, see section Common notes please.
Note for laptop and PREPROM-02aLV users
Since the PREPROM-02aLV programmer is supplied with 12V,
notebook and/or laptop users may operate their PREPROMs-
02aLV everywhere this voltage is available, e.g. in a car. Ten
series-connected NiCd batteries can supply the programmer
for more than one hour at full performance.
swapping has no effects - the programmer is protected against
the reversal of the power supply poles. The supply cable you
can make yourself, polarity is:
Manipulation with the programmed
device
After selection of desired device for your work, you can insert
into the open ZIF socket (the lever is up) and close socket (the
lever is down). The correct orientation of the programmed
device in ZIF socket is shown on the picture near ZIF socket
on the programmer's cover. The programmed device is
necessary to insert into the socket also to remove from the
socket when LED BUSY light off.
Warning: PREPROM-02aLV programmer hasn't protection
devices, which protect the content of programmed device
against critical situations, for example power failures and PC
failure (interrupted cable...). Moreover, a device is usually
destroyed in the programming mode due to forced interruption
of the control program run (Reset or switching the computer
off) due to removing the connecting cable, or unplugging the
programmed device from the ZIF socket. Incorrectly placed
device in the ZIF socket can cause its damage or destruction.

Selftest and calibration

If you feel that your programmer does not react according to
your expectation, please run the programmer selftest using
Diagnostic POD, enclosed with the standard delivery package.
For optimal results with programmer we recommend you
65
