Elnec JetProg User Manual page 128

When "Split serial number at every 4 byte(s)" is set, the
buffer content will look as:
Byte buffer organization:
Address
0000080
Word16 buffer organization:
Address
0000040
Advice: When you are not sure about effects of
serialization options, there is possible to test the real serial
number, which will be written to buffer. The test can be
made by following steps:
1. select
Serialization and confirm these by OK button
2. in dialog Device operation options set Insertion test and
Device ID check (if available) to Disabled
3. check there is no device inserted to programmer's ZIF
socket
4. run Device Program operation (for some types of
devices it is necessary to select programming options
before programming will start)
5. after completing programming operation (mostly with
some errors because device is not present) look at the
main buffer (View/Edit buffer) at address where serial
number should be placed
Note: Address for Serialization is always assigned to actual
device organization and buffer organization that control
program is using for current device. If the buffer
organization is byte org. (x8), the Serialization Address will
be byte address. If the buffer organization is wider than
byte, e.g. 16 bit words (x16), the Serialization Address will
be word address.
Device / Device options / Serialization / From
file mode
Using the From-file method, serial values are read from the
user specified input file and written to buffer on address
specified in input file.
There are two user options: File name and Start label.
File name
File name option specifies the file name from which serial
addresses and values will be read. The input file for From
file serialization must have special format, which is
described in From file serialization file format below.
Start label
Data
CD xx xx xx AB xx xx xx 34 xx xx xx 12
Data
xxCD xxxx xxAB xxxx xx34 xxxx xx12 xxxx
wished serialization
128
ELNEC s. r. o.
options in dialog
