Introduction

JetProg
95/98/Me/NT/2000/XP based ELNEC universal programmers
built to meet the rigorous demands of the leading engineers
and programming centers.
JetProg supports all kinds of types and silicon technologies of
programmable devices. It provides very competitive price but
excellent hardware design for reliable programming. Best
"value for money" in this class.
JetProg interfaces with the IBM PC 486 compatible or higher,
portable or desktop personal computers. Programmer allows
you to directly connect to your PC through any standard
parallel (printer) port (no special interface card needed). We
recommend use parallel (printer) port on PCI bus, IEEE
1284 compatible (ECP/EPP). The JetProg control program
support standard IEEE1284 also.
JetProg offer very fast programming due high-speed FPGA
driven hardware and support of ECP/EPP parallel port.
Consequently and due special protocol is communication
between PC and JetProg programmer fast and very reliable.
The programming AT29C040A takes about 28 seconds it is
faster than most its competitors. As a result, this programmer
is optional solution for middle quantities programming in
production or programming centers.
JetProg, base configuration
• JetProg, base unit
• JetProg, DIL48 socket module
For following text, term JetProg means JetProg in base
configuration.
is a new
16
generation
ELNEC s. r. o.
of Windows
