or by loading file with proper content). The bottom 8
bits of each RETLW instruction are not important
now, because serialization will write correct serial
number bytes at bottom 8 bits of each RETLW
instruction.
The buffer content before starting device program will
look for example as following:
Address Data
0000040
8 bits of each RETLW instructions are zeros, they
can have any value.
b) Set the serialization options as following:
S/N size 4 Bytes
Address: 40H
Start value: 1234ABCDH
Step: 1
S/N mode: BIN
Style: HEX
Save to buffer: LS Byte first
Check the option "Split serial number at every N
byte(s)" and split value N set to 2.
(It means split of serial number to buffer at every
second Byte)
The correct serial number is set tightly before device
programming operation starts.
The buffer
programming the first device is:
Address Data
0000040 34CD 34AB 3434 3412 xxxx xxxx xxxx xxxx
That's it.
3. Following example uses the same serialization options as
Example number 2, instead the serial number split is set
to 3 and 4.
When "Split serial number at every 3 byte(s)" is set, the
buffer content will look as:
Byte buffer organization:
Address Data
0000080 CD xx xx AB xx xx 34 xx xx 12 xx xx xx xx xx xx
Word16 buffer organization:
Address Data
0000040 xxCD ABxx xxxx xx34 12xx xxxx xxxx xxxx
3400 3400 3400 3400 xxxx xxxx xxxx xxxx
