(big endian). Standard save file operation is using little endian
byte order.
The reserved key <F2> will bring out this menu from any menu
and any time.
File / Load project
This option is used for loading project file, which contains
device configuration buffer data saved and user interface
configuration.
The standard dialog Load project contains additional window
- Project description - placed at the bottom of dialog. This
window is for displaying information about currently selected
project file in dialog Load project.
Project information consists of:
• manufacturer and name of the first device selected in the
project
• date and time of project creation
• user written description of project (it can be arbitrary text,
usually author of project and some notes)
File / Save project
This option is used for saving project file, which contains
settings of device configuration and buffer data saved. Data
saved to project file can be restored anytime by menu
command File / Load project.
The dialog Save project contains three additional windows in
Project description panel placed at the bottom of dialog Save
project. The windows are for displaying information about
currently selected project file in dialog Save project and
information about current project, which has to be saved.
Dialog Save project contains also additional button with
picture of key displayed. Clicking on this button password
dialog appears which can be used to save project with
password. Projects with password are special projects also
called Protected
information about project passwords see Options / Protected
mode.
Project information consists of:
• manufacturer and name of the first device selected in the
project
• date and time of project creation
• user written description of project (it can be arbitrary text,
usually author of project and some notes)
The first (upper) window contains information about currently
selected project file in dialog Save project.
mode projects.
