Note:
Bit No.
The state word reflects the operation state.
Switched-off
Switch-on inhibit
Ready to switch-on
Quick-stop
Ready
Operation enabled
Fault
Fault reaction active
(*) without considering bits 7 to bit 15
The shaded commands are the commands relevant for the simplified state machine.
The Warning bit "Bit No. 7" can be set at any time. It displays an device-internal
warning message. The evaluation of the warning available is done by reading out the
warning status with the parameter
The Remote bit "Bit No. 9" is set if the operation mode control via state machine
Local/Remote
(
Logic linking of the digital control signals:
Only if the logic linking is true the frequency inverter can be controlled via the control
word.
The bit Reference value reached "Bit No. 10" is set when the reference value
specified has been reached. In the special case of power failure regulation, the bit is
also set if the power failure regulation has reached the frequency 0 Hz (see operating
instructions). For "Reference value reached" there is a hysteresis (tolerance range),
which can be set via the parameter
instructions).
The bit Limit value active "Bit No. 11" displays that an internal limit is active. This
can, for example, be the present current limit, the torque limit or the over-voltage
limit. All the functions lead to the reference value being quit or not reached.
The bit Warning 2 "Bit No. 15" reports a warning which leads to a fault switch-off
of the frequency inverter within a short time. This bit is set if there is a warning for
motor temperature, heat sink/inside temperature, Ixt monitoring or mains phase
failure.
38
38
A fault occurring leads to a switch-over to the "Fault" state. The
acknowledge of the fault is done by a positive edge of Bit 7.
A fault can only be acknowledged 15 seconds after the occurrence of the
fault, as a blocking time is active internally.
State word
Name
0
Ready to switch on
1
Ready
2
Operation enabled
3
Fault
4
Voltage inhibit
5
Quick stop
6
switch on inhibit
7
Warning
Meaning
HEX (*) Bit 6
412 = 1) has been set and the hardware release is available.
( S1IND AND ( S2IND OR S3IND ) )
State word
Bit No.
8
9
Remote
10
Reference value reached
11
Limit value reached
12
13
14
15
Warning 2
State word
Bit 5
0x00
0
x
0x40
1
x
0x21
0
1
0x07
0
0
0x23
0
1
0x27
0
1
0x08
0
x
0x0F
0
x
Warnings
270.
max. Control deviation
Name
-
-
-
-
Bit 3
Bit 2
Bit 1
0
0
0
0
0
0
0
0
0
0
1
1
0
0
1
0
1
1
1
0
0
1
1
1
549 (see operating
Bit 0
0
0
1
1
1
1
0
1
06/05
06/05
