4
The CAN connection is physically designed according to the ISO 11898 standards
(CAN High-Speed).
S1
The factory setting for the bus connection is OFF.
As an alternative, this also possible via corresponding switching in the bus connection
plugs.
Attention: Make absolutely sure that only one of the two possibilities for the bus
The drilled and shielded line is to be used for the bus line. The shield is to be
implemented as a harness shield (not a film shield).
Attention! The line screen is to be connected with PE on the surface at both ends.
06/05
06/05

Plug occupancy/bus connection/line

data line
data line
connection is used and the bus connection is only switched on with the
first and last subscriber. Otherwise, operation of the CANopen
communication is not possible.
Pin Name
Housing Shield
1 CAN_L
2 CAN_L
3 CAN_GND
4 n.c.
5 n.c.
6 CAN_GND
7 CAN_H
8 CAN_H
9 +5V out
The X310 (9-pole Sub-D) bus plug has been
designed according to DS102 Version 2.0 (Bus
node, option A).
Details can be seen from the following table on
the occupancy of the bus plug.
The bus connection necessary on a phase in the
X310
physically first and last subscriber can be
activated via
communication module.
CAN high (Pin 7)
120 Ω
CAN low (Pin 2)
Bus plug X310
connected with PE
CAN Low bus interface,
short-circuit resistant and function-insulated,
max. current 60 mA
CAN Low bus interface,
short-circuit resistant and function-insulated,
max. current 60 mA
Earth / GND
not used
not used
Earth / GND
CAN High bus interface,
short-circuit resistant and function-insulated,
max. current 60 mA
CAN-High Bus-interface,
short-circuit resistant and function-insulated,
max. current 60 mA
Supply voltage
DIP switch S1
Function
on the
