Tally Dascom DT-210/230

7.5 Paper Specification

Paper type
Form
Size
• Paper must not be pasted to the roll paper spool.
• The remaining amount of the roll paper when a roll
paper near-end is detected differs depending on the spool
type.

7.5.1 Printable Area

80 mm paper width printing
The printable area of a paper with width of 79.5 ± 0.5 mm {3.13 ± 0.02"} is 72.2 ± 0.2 mm {2.84 ± 0.008"}
(576 dots) and the space on the right and left sides are approximately 3.7 ± 2 mm {0.15 ± 0.079"}.
3.7 mm {0.15}
Roll paper diameter
Min. core diameter
Take-up roll paper
width
Paper width
79.5 ± 0.5 mm {3.13 ± 0.02"}
0.141 ± 0.05 mm {0.056 ± 0.002"}
72.2 ± 0.2 mm {2.84 ± 0.008"}
Specified thermal paper
Roll paper
83 mm {3.27"} maximum
13mm
80 + 0.5/-1.0 mm
79.5 ± 0.5 mm
CAUTION
3.7 mm {0.15}
62
User Guide V1.3
All the numeric values are typical.
