Queue Policing

This page allows you to configure the Queue Policer settings for all switch ports.
Label Description
Port The port number for which the configuration below applies.
Enable(E) Controls whether the queue policer is enabled on this queue.

Port Scheduler

This page provides an overview of QoS Egress Port Schedulers for all switch ports.
Label Description
Port The logical port for the settings contained in the same row.
Click on the port number in order to configure the schedulers.
Mode Shows the scheduling mode for this port.
Qn Shows the weight for this queue and port.
