Chapter 1: Overview
Board Component Blocks
■
General user input/output
■
■
■
■
Power supply
■
■
■
Mechanical
■
■
System Monitoring—Power (voltage, current, wattage)
August 2017 Altera Corporation
LEDs and displays
Eight user LEDs
■
One configuration load LED
■
One configuration done LED
■
One error LED
■
Four embedded USB-Blaster II status LEDs
■
Six HSMC interface LEDs
■
Four PCI Express link width LEDs (mirrored on top and bottom)
■
Five Ethernet LEDs
■
One SDI carrier detect LED
■
One power on LED
■
One two-line character LCD display
■
Push buttons
One CPU reset push button
■
One MAX V reset push button
■
One program select push button
■
One program configuration push button
■
Three general user push buttons
■
DIP switches
Two board settings DIP switches
■
JTAG chain control or PCI Express link width DIP switch
■
FPGA configuration mode DIP switch
■
One general user DIP switch
■
19-V (laptop) DC input
PCI Express edge connector
PCI Express half-length form factor (4.376" x 6.600")
Cyclone V GT FPGA Development Board
Reference Manual
1–3
