Board Overview

This section provides an overview of the Cyclone V GT FPGA development board,
including an annotated board image and component descriptions.
an overview of the board features.
Figure 2–1. Overview of the Cyclone V GT FPGA Development Board Features
Table 2–1
Table 2–1. Board Components (Part 1 of 4)
Board Reference
Featured Devices
U13
FPGA
U32
CPLD
Configuration, Status, and Setup Elements
J13
JTAG chain header
JTAG chain control or
SW3
PCI Express DIP switch
Cyclone V GT FPGA Development Board
Reference Manual
describes the components and lists their corresponding board references.
Type
Cyclone V GT, 5CGTFD9E5F35C7N, 1152-pin FBGA.
MAX V CPLD, 5M2210ZF256C4N, 256-pin FBGA.
Provides access to the JTAG chain and disables the embedded
USB-Blaster II when using an external USB-Blaster cable.
Remove or include devices in the active JTAG chain. Also controls the
PCI Express lane width by connecting the prsnt pins together on the
PCI Express edge connector.
Chapter 2: Board Components
Figure 2–1
Description
August 2017 Altera Corporation
Board Overview
shows
