Table 2–1. Board Components (Part 3 of 4)
Board Reference
J3, J6 Clock input SMA connectors
J4, J7 Clock output SMA connectors
J14 SMA connector
General User Input/Output
D8–D11, D15–
User LEDs
D18
SW1 User DIP switch
S4 CPU reset push button
S7 MAX V reset push button
S1–S3 General user push buttons
Memory Devices
U26, U27, U28 DDR3 x40 memory
U8, U15, U22,
DDR3 x64 memory
U30
U20 Flash x16 memory
Communication Ports
J16 PCI Express edge connector
J1, J2 HSMC port
J9 Gigabit Ethernet port
Video and Display Ports
J10 Character LCD
J11, J12 SDI video port
Power Supply
J16 PCI Express edge connector
J8 DC input jack
Cyclone V GT FPGA Development Board
Reference Manual
Type
Drive LVPECL-compatible clock inputs into the clock multiplexer
buffer.
Drives out 2.5-V CMOS clock output from the clock buffer (U3).
SMA to or from the FPGA, which can be an I/O or a clock output.
Eight user LEDs. Illuminates when driven low.
Quad user DIP switches. When the switch is ON, a logic 0 is selected.
Reset the FPGA logic.
Reset the MAX V CPLD 5M2210 System Controller.
Three user push buttons. Driven low when pressed.
Three 128-MB DDR3A SDRAM with ECC, each with a 16-bit data bus
for a hard memory controller.
Four 128-MB DDR3B SDRAM, each with a 16-bit data bus for a soft
memory controller.
1-Gb synchronous flash devices with a 16-bit data bus for non-volatile
memory.
Gold-plated edge fingers connector for up to ×4 signaling in Gen1
mode.
Two ports, one with four transceiver channels and 84 CMOS or 17
LVDS channels as per the HSMC specification, and one with CMOS I/O
assignments and DQS/DQx32 assignments for future use.
RJ-45 connector which provides a 10/100/1000 Ethernet connection
via a Marvell 88E1111 PHY and the FPGA-based Altera Triple Speed
Ethernet MegaCore function in RGMII mode.
Connector that interfaces to a provided 16 character × 2 line LCD
module along with four standoffs.
Two 75-Ω sub-miniature version B (SMB) connectors that provide a
full-duplex SDI interface through a LMH0303 cable driver and
LMH0384 cable equalizer. By default, this is not an active interface but
is only available when you switch the resistor placement. After making
this resistor change, the HSMC port A transceiver channel 3 is no
longer available.
Interfaces to a PCI Express root port such as an appropriate PC
motherboard.
Accepts a 19-V DC power supply. Do not use this input jack while the
board is plugged into a PCI Express slot.
