MBTCP.STATUS.GeneralStatus.
Client1to19CmdExecutionWord
MBTCP.STATUS.GeneralStatus.
EventSeqReady
MBTCP.STATUS.GeneralStatus.
MNetRequestCount
MBTCP.STATUS.GeneralStatus.
MNetResponseCount
MBTCP.STATUS.GeneralStatus.
MnetErrorSent
MBTCP.STATUS.GeneralStatus.
MNETErrorReceived
MBTCP.STATUS.GeneralStatus.
MBAPRequestCount
MBTCP.STATUS.GeneralStatus.
MBAPResponseCount
MBTCP.STATUS.GeneralStatus.
MBAPErrorSent
MBTCP.STATUS.GeneralStatus.
MBAPErrorReceived
MBTCP.STATUS.GetEventDataStatus
This array contains the status of the event command last executed.
Tag Name
MBTCP.STATUS.GetEventData
Status.ClientRecordsCount
MBTCP.STATUS.GetEventData
Status.Status
ProSoft Technology, Inc.
June 28, 2017
0 = Disable, 1 = Enable
Each bit in each of the 19 words is used to enable/disable the
commands for clients 1 to 19.
0 = Disable, 1 = Enable
Bit mapped (1 bit per client 0 to 19)
Bit = 0, no event sequence status data ready
Bit = 1, event sequence status data ready
Increments each time an encapsulated Modbus TCP/IP (Service
port 2000) request is received.
Increments each time an encapsulated Modbus TCP/IP (Service
port 2000) response message is sent.
Increments each time an error is sent from a server on service
port 2000.
Increments each time an error is received from a server on
service port 2000.
Increments each time a MBAP (Service port 502) request is
received.
Increments each time a MBAP (Service port 502) response
message is sent.
Increments each time an error is sent from the server on service
port 502.
Increments each time an error is received from a server on
service port 502.
Description
Number of clients contained in block (0 to 19)
Two words per client.
Word 1 = Client (0 to19)
Word 2 = Error code for last executed command for
corresponding client
Using Controller Tags
