MVI69E-MBTCP ♦ CompactLogix Platform
Modbus TCP/IP Enhanced Communication Module
5
Click OK. The new module is now visible.
6
You must also import the Add-On Instruction(AOI) for the new module (see
Adding another module in PCB). In the Controller Organizer pane, double-
click M
AIN
ProSoft Technology, Inc.
June 28, 2017
R
to open the ladder for the routine.
OUTINE
Adding the Module to RSLogix
User Manual
Page 37 of 150
