Reference
User Manual
Block 9997: Response from Module to Processor
Offset Description
0 Block ID 9997
1 Write Block ID
2-n Spare

7.4.21 Warm-boot Control Block (9998)

If the CompactLogix sends a block number 9998, the module performs a warm-
boot operation. The module reconfigures the communication ports and reset the
error and status counters.
Block 9998: Request from Processor to Module
Offset Description
0 Block ID 9998
1 to (n-1) Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.

7.4.22 Cold-boot Control Block (9999)

If the CompactLogix processor sends a block number 9999, the firmware
performs a cold-boot operation. The firmware reloads the configuration file from
the processor to the module and resets all MBTCP memory, error and status
data.
Block 9999: Request from Processor to Module
Offset Description
0 Block ID 9999
1 to (n-1) Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
