Using Controller Tags
User Manual
MBTCP.STATUS.EventSeqCounts
This array indicates the number of commands waiting in the command queue.
Tag Name
MBTCP.STATUS.EventSeqCounts.
ClientCmdCount_EventSeqMessage
Byte 1: Number of Event sequence commands for which status has not yet been
retrieved (up to 15). This corresponds to the
MNETC.STATUS.EventSeqCmdPending.Client[x]_QueueCount controller tag.
Byte 2: Total number of commands waiting in the command queue. This includes
Event Commands, Event Commands with Sequence Numbers, and Command
Control messages. This corresponds to the
MBTCP.STATUS.EventSeqStatus.MessageCount controller tag.
MBTCP.STATUS.GeneralStatus
This array contains the general status of the module including firmware revision
and general communication status.
Tag Name
MBTCP.STATUS.GeneralStatus.
ExpectedWriteBlock
MBTCP.STATUS.GeneralStatus.
ProgramScanCount
MBTCP.STATUS.GeneralStatus.
ProductCode
MBTCP.STATUS.GeneralStatus.
ProductVersion
MBTCP.STATUS.GeneralStatus.
OperatingSystem
MBTCP.STATUS.GeneralStatus.
RunNumber
MBTCP.STATUS.GeneralStatus.
ReadBlockCount
MBTCP.STATUS.GeneralStatus.
WriteBlockCount
MBTCP.STATUS.GeneralStatus.
ParseBlockCount
MBTCP.STATUS.GeneralStatus.
CmdEventBlockCount
MBTCP.STATUS.GeneralStatus.
CmdBlockCount
MBTCP.STATUS.GeneralStatus.
ErrorBlockCount
MBTCP.STATUS.GeneralStatus.
Client0CmdExecutionWord
Page 88 of 150
Modbus TCP/IP Enhanced Communication Module
Description
Event command quantity waiting in queue. There are two
bytes of status data per client. See below for details.
Description
Contains the next write block ID number
Program cycle counter – increments each time a complete
program cycle occurs in the module
Product code
Firmware revision level number
Operating level number
Run number
Total number of read blocks transferred from the module to the
processor
Total number of write blocks transferred from the processor to
the module
Total number of blocks successfully parsed that were received
from the processor
Total number of event command blocks received from the
processor
Total number of command blocks received from the processor
Total number of block transfer errors recognized by the module
Each bit in this word is used to enable/disable the commands for
client 0.
