MVI69E-MBTCP ♦ CompactLogix Platform
Modbus TCP/IP Enhanced Communication Module

7.4.19 Pass Module Time to Processor Block (9973)

This block uses the time information of the module to set the processor time.
Block 9973: Request from Processor to Module
Offset
Description
0
Block ID 9973
1-n
Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
Block 9973: Response from Module to Processor
Offset
Description
0
Block ID 9973
1
Write Block ID
2
Year (0-9999)
3
Month (1-12)
4
Day (1-31)
5
Hour (0-23)
6
Minutes (0-59)
7
Seconds (0-59)
8
Milliseconds
9 to (n-1)
Spare

7.4.20 Reset Status Block (9997)

This block resets the module, port 1, and/or port 2 status.
Block 9997: Request from Processor to Module
Offset
Description
0
Block ID 9997
Reset Module status:
1
0=no, else yes
Reset Port 1 status:
2
0=no, else yes
Reset Port 2 status:
3
0=no, else yes
4 to (n-1)
Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
ProSoft Technology, Inc.
June 28, 2017
Reference
User Manual
Page 143 of 150
