Adding the Module to RSLogix
User Manual
2 Enter
GENERIC
you're using an earlier version of RSLogix, expand O
Module dialog box, and then select the G
3 Set the Module Properties values as follows:
Parameter
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance
Configuration Size
Page 22 of 150
in the search text box and select the G
Value
Enter a module identification string. Example: MVI69E_MBTCP
Enter a description for the module. Example: ProSoft
communication module for Serial Modbus communications.
Select D
Enter the slot number in the rack where the MVI69E-MBTCP
module is installed.
101
62 / 122 / 242
100
61 / 121 / 241
102
0
MVI69E-MBTCP ♦ CompactLogix Platform
Modbus TCP/IP Enhanced Communication Module
ENERIC
THER
1769 M
ENERIC ODULE
-INT
ATA
1769 M . If
ODULE
in the Select
.
