The following illustration shows an example where the module was
configured for a block transfer size of 60 words (input block size = 62 words,
output block size = 61 words):
The following options are available:
Block Transfer Size
60
120
240
4 On the Connection tab, set the R
project and click OK.
ProSoft Technology, Inc.
June 28, 2017
Input Block Size
62
122
242
P
EQUESTED ACKET
Adding the Module to RSLogix
Output Block Size
61
121
241
I value for your
NTERVAL
