Operation Instructions

The FD70CV-M-C-6 is continuously on but can be de-energized by removing power from
the entertainment system. The user can change the video output from the FD70CV-M-C-
6 using the video source select switch on the LCD monitor. When power is applied, the
display will turn on and look for a valid input on the last known source. If no input is
found, the display will go to standby mode.
Monitor Control Buttons
Button Function
