- Page 1 Revision Date: Rev: Document Number: 01/10/2017 MAN – FD090CV Page 1 of 19 Installation and Operation Manual FD090CV 9” TFT LCD © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
-
Page 2: Table Of Contents
Access the Menu Systems ................12-15 Technical Drawing ....................16 Technical Support ....................17 Instructions for Continued Airworthiness ............17 Warranty ......................18 Log of Revisions ....................19 © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 3: General Information
Page 3 of 19 General Information The FD090CV is the latest version of our popular 9” TFT LCD. TFT stands for Thin Film Transistor, and is a type of technology used to improve the image quality of an LCD. This unit is a full function 9-inch LCD housed in a metal case that will fit on most aircraft. -
Page 4: Specifications
RTCA DO-160 – Sec 21 CAT B RTCA DO-160 – Sec 21 CAT M NOTE: THIS PRODUCT IS NOT HDCP COMPLIANT, THERFORE IT WILL NOT WORK WITH BLU-RAY PLAYERS © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 5: Installation Instructions
Page 5 of 19 Installation Instructions All cabin entertainment equipment, such as the FD090CV should be installed on a non- essential bus and have a dedicated circuit breaker. This unit mounts to the aircraft’s pre- installed bracket using 4-40 screws. -
Page 6: Video Wiring Suggestions
Deerfield Laboratory, Inc. Part No. 162-1 (www.deerfieldlab.com, (650) 632-4090). In most cases this should be added to the video output of the source. © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 7: Vga Wiring
5 separate coaxial cables, color-coded to match the functions of the wires. We recommend coax cables be terminated using solder sleeve coaxial cable terminators such as Raychem Part Number CWT-4174-W122-5/9. © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. -
Page 8: Composite
Part Numbers for DB-9 connectors, manufactured by Tyco or Amp. D-sub, 9 contact receptacle (female) P/N 205203-1 DB9F pins P/N M39029/63-368 Description Number 28VDC INPUT 28 VDC RETURN © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 9: Hdmi
The plug’s outside dimensions are 13.9 mm wide by 4.45 mm high. ECS manufactures an HDMI cable that is terminated at the factory. It is ordered as part number 600-19786-XXX, where XXX is the length in inches for the desired cable. © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. -
Page 10: Power & Ground Wiring
Operation Instructions The FD090CV is continuously on but can be de-energized by removing power from the entertainment system. No pilot or aircrew action is necessary during flight or ground operation. Passengers can change the video output from the FD090CV using the remote control. -
Page 11: Remote Control Buttons
Moves to the previous selection in the menu. Decrease the selection’s value in the menu. LEFT Increases the selection’s value in the menu. RIGHT SOURCE Switches between sources coming into the display. © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 12: Access The Menu Systems
Allows the user to correct flickering text or lines. Frequency Adjusts the frequency (clock) of the screen. Scaling Adjusts the screen size. Auto Adjust Automatically adjusts the picture to the most appropriate display area. © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 13: Advanced Menu
Adjust to increase or decrease the red tones. User Green Adjust to increase or decrease the green tones. User Blue Adjust to increase or decrease the blue tones. © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... - Page 14 Select to display all on-screen settings in your language of choice: English, Spanish, French (Not Available). Backlight Sets the PWM level of the panel backlight (not available). © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
-
Page 15: Utilities Menu
Not supported on this feature – Disable VGA Input Enable Supported input – Enabled DVI Input Enable Not supported on this feature – Disable CVBS1 Input Enable © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 16: Technical Drawing
Revision Date: Rev: Document Number: 01/10/2017 MAN – FD090CV Page 16 of 19 Technical Drawing © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 17: Technical Support
01/10/2017 MAN – FD090CV Page 17 of 19 Technical Support Should you have any questions concerning this product or other FDS Avionics Corp. products, please contact our Product Support representatives at (470) 239-7421. FDS Avionics Corp. 6435 Shiloh Road Alpharetta, GA 30005... -
Page 18: Warranty
Limited Warranty All FDS Avionics Corp. products are warranted to be free from material or manufacturing defects for a period of 24 months from the date of shipment for General Aviation customers or 12 months from the date of shipment for Government/Special Mission customers. -
Page 19: Log Of Revisions
Page Description 03/22/2013 Initial Release Address, Warranty, Button References changed to Remote 04/21/2014 Access, Menus added Changed Company Name and Formatting – No Revision 01/10/2017 Change necessary © 2015 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
