HARDWARE INSTALLATION GUIDE
Brocade ICX 6430 and ICX 6450
Stackable Switches
Hardware Installation Guide
Part Number: 53-1003617-03
Publication Date: 15 June 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICX 6430 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brocade Communications Systems ICX 6430

Summary of Contents for Brocade Communications Systems ICX 6430

  • Page 1 HARDWARE INSTALLATION GUIDE Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03 Publication Date: 15 June 2017...
  • Page 2 United States government. The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.

  • Page 3: Table Of Contents

    Installing the device..............................................28 Desktop installation............................................28 Rack mount installation..........................................29 Wall mount installation..........................................32 Connecting devices in a traditional stack...................................... 34 Stacking ports and trunks...........................................35 Stacking configuration requirements..................................... 36 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 4 Devices running Layer 3 software......................................71 Connecting network devices..........................................73 Connectors............................................... 73 Cable specifications............................................73 Connecting to Ethernet or Fast Ethernet hubs.................................. 74 Connecting to workstations, servers, or routers................................75 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 5 Troubleshooting ..........................................97 Diagnosing switch indicators..........................................97 Installation................................................. 97 Power and cooling problems........................................97 In-band access............................................... 97 Regulatory Statements........................................99 CE Statement................................................99 China ROHS................................................99 BSMI statement (Taiwan)............................................. 99 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 6 Cautions and Danger Notices..................................... 103 Cautions................................................... 103 General cautions............................................103 Electrical cautions............................................104 Danger Notices..............................................105 General dangers............................................106 Electrical dangers............................................106 Dangers related to equipment weight....................................107 Laser dangers.............................................. 107 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 7: Preface

    Identifies the names of GUI elements. Identifies text to enter in the GUI. italic text Identifies emphasis. Identifies variables. Identifies document titles. Identifies CLI output. Courier font Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 8: Command Syntax Conventions

    Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 9: Contacting Brocade Technical Support

    Brocade Supplemental Support augments your existing OEM support contract, providing direct access to Brocade expertise. For more information, contact Brocade or your OEM. • For questions regarding service levels and response times, contact your OEM/solution provider. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 10 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 11: About This Document

    There are no enhancements in this edition. Supported Software For information about the features supported on a hardware platform, refer to the appropriate Features and Standards Support Matrix document. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 12 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 13: Icx 6430 And Icx 6450 Overview

    Power supplies........................................22 Hardware features The following sections describe the physical characteristics of the ICX 6430 and ICX 6450 devices. For more details about physical dimensions and power supply specifications, refer to the Brocade ICX 6430 and ICX 6450 Stackable Switches Technical Specifications on page 91.

  • Page 14: Icx 6450 Models

    ICX 6450-48P — 48 10/100/1000 Mbps PoE+ copper ports and 4 ports with 1 or 10 Gbps SFP+ fiber uplink and stacking ports NOTE The ICX 6450-24P and ICX 6450-48P devices support up to 802.3 at PoE+. FIGURE 7 ICX 6450-24 and ICX 6450-24P front panels Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 15: Network And Management Interfaces

    These RJ-45 management ports are located together in the middle of the front panel on 24-port models, and on the left side of the front panel on 48-port models. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 16: Console Management Interface

    PC. Out-of-band management interface The out-of-band management interface is an RJ-45 port that allows you to configure and manage the device from the network. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 17: System Reset Button

    SFP or SFP+ fiber ports ICX 6430 and ICX 6450 devices contain four small form factor pluggable (SFP) ports (ports 1 through 4). The top row consists of ports 1 and 3, and the bottom row consists of ports 2 and 4. These ports reside on slot 2 of the stackable switch and can be used as uplink (data) ports or stacking ports.

  • Page 18: Specifying A Port Address

    • stack unit --Specifies the stack unit ID. For the ICX 6430, the range is from 1 through 4. For the ICX 6450, the range is from 1 through 8. If the device is not part of a stack, the stack unit ID is 1.

  • Page 19: Port, System, And Power Status Leds

    Port, system, and power status LEDs Port, system, and power status LEDs ICX 6430 and ICX 6450 devices include LEDs that indicate the status of device components. FIGURE 15 Port status LEDs on 24-port models Port status LEDs FIGURE 16 Port status LEDs on 48-port models...
  • Page 20 10/100 Mbps Link-up. Flashing indicates the port is transmitting and receiving user packets. FIGURE 17 System status LEDs on ICX 6430-48P 48-port model System status LEDs TABLE 3 System status LEDs on ICX 6450 and ICX 6430 devices Condition Status EPS1 and EPS2...
  • Page 21 Power status LED on the ICX 6430-48 and ICX 6430-48P models NOTE The location of the power status LED on the front panel of the ICX 6430-48 and ICX 6430-48P devices is the same on the ICX 6430-24P device, ICX 6450-24 device, ICX 6450-24P device, and the ICX 6450-48 device.

  • Page 22: Power Supplies

    Power supplies ICX 6430 and ICX 6450 devices have one standard power supply receptacle on the rear panel of the device for the AC power cord. The connector labeled "EPS" is for the optional external power supply cord that can provide power to the device in the event the internal power supply fails.

  • Page 23: Power Supply Usage

    ICX 6450-48 ICX 6450-48P Power supply usage The ICX 6430 and ICX 6450 models support specific AC power supply inputs and numbers of PoE and PoE+ ports with an internal power supply. NOTE Each EPS connection from the device to the ICX 6400-EPS1500 can add 24 ports of PoE or 12 ports of PoE+ power in addition to the internal power supply by providing system power backup.
  • Page 24 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 25: Icx 6430 And Icx 6450 Installation

    Items included with the ICX 6430 and ICX 6450 devices ICX 6430 and ICX 6450 devices ship with all of the following items included in your shipping container. Verify the contents of your shipping container. If any items are missing, contact the place of purchase.

  • Page 26: Summary Of Installation Tasks

    DANGER Mount the devices you install in a rack as low as possible. Place the heaviest device at the bottom and progressively place lighter devices above. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 27: Power Precautions

    Allow for the unit to be connected to a separate grounded power outlet that provides 100 to 240 VAC, 50 to 60 Hz, is within 2 m (6.6 ft) of each device, and is powered from an independent circuit breaker. As with any equipment, a filter or surge suppressor is recommended. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 28: Rack-Mount Installation Considerations

    Mount the devices you install in a rack as low as possible. Place the heaviest device at the bottom and progressively place lighter devices above. Desktop installation Complete the following steps to install the ICX 6430 or ICX 6450 device on a desktop or other flat surface. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 29: Rack Mount Installation

    Complete the following steps to mount devices in a rack. Remove the rack mounting kit from the shipping carton. The kit contains two L-shaped mounting brackets and six sink-head screws. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 30 Using a Phillips screwdriver, attach the mounting brackets to the sides of the device using six sink-head screws. FIGURE 22 Attaching the rack mounting brackets for ICX 6430 and ICX 6450 devices Remove the two-post rack kit from the shipping carton. The kit contains four rack-mounting screws and four cage nuts.
  • Page 31 Using a Phillips screwdriver, mount the device in a two-post rack using four rack-mounting screws. NOTE The ICX 6430 and ICX 6450 devices must be installed on two-post racks only. The devices cannot be installed on four-post racks. FIGURE 23 Installing the device in a two-post rack...

  • Page 32: Wall Mount Installation

    You need a #2 Phillips screwdriver, a hammer, and a drill for wall mount installation. Mounting the device to a wall is only applicable to ICX 6430-24, ICX 6430-24P, ICX 6450-24, and ICX 6450-24P devices. Brocade recommends that you wall mount the device with the port side down.
  • Page 33 Using a Phillips screwdriver, attach the wall mount brackets to the sides of the device using four sink-head screws. FIGURE 24 Attaching the wall mount brackets for ICX 6430-24 devices Drill two holes on the wall where you want to mount the device.

  • Page 34: Connecting Devices In A Traditional Stack

    Connecting devices in a traditional stack ICX 6430 devices and ICX 6450 devices can operate as standalone devices and also as members of traditional stacks. A stack is a group of devices—Brocade stackable units and their connected stacking links—that are connected so that the stack is managed as a single entity.

  • Page 35: Stacking Ports And Trunks

    Stacking ports and trunks There are four SFP ports (ICX 6430) or four SFP+ ports (ICX 6450) on the front panels that can be used as uplink (data) ports or as stacking ports. The figure below shows the ports in slot 2; the top row consists of ports 1 and 3, and the bottom row consists of ports 2 and 4.

  • Page 36: Stacking Configuration Requirements

    1-Gbps ports are 1 meter and 5 meters. The copper cable lengths for 10-Gbps ports are 1 meter, 3 meters, and 5 meters. Stack size A traditional stack can contain a maximum of eight ICX 6450 devices or four ICX 6430 devices. A traditional stack cannot contain both ICX 6430 and ICX 6450 devices. Stacking topologies Both linear and ring topologies are supported in a traditional stack.
  • Page 37 Connecting devices in a traditional stack FIGURE 27 Linear and ring stacking topologies using one port per trunk Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 38 Connecting devices in a traditional stack FIGURE 28 Linear stacking topology using both ports in each trunk FIGURE 29 Ring stacking topology using both ports in each trunk Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 39: Connecting Devices In A Mixed Stack

    You can trunk stacking ports by connecting one port of each type (40 Gbps or 4 x 10 Gbps) to ports of the same type on another ICX 6610 device in the stack. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 40 The following first figure shows the 10 Gbps SFP+ ports in slot 3 of a 24-port device. The following second figure shows the 10 Gbps SFP+ ports in slot 3 of a 48-port device. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 41: Icx 6450 Stacking Ports And Trunks

    2; the top row consists of ports 1 and 3, and the bottom row consists of ports 2 and 4. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 42: Stacking Configuration Requirements

    If you use the Secure Setup utility to set up a mixed stack, the stacking units (ICX 6610 devices and ICX 6450 devices) are automatically trunked. Stacking configuration requirements The stacking configuration requirements are describes in the sections below. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 43: Stacking Cables

    You can connect stacking units using one port per trunk or both ports in a trunk. For maximum bandwidth and link redundancy, use both ports per trunk on all stack units. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 44 In the following figure, two ICX 6610 devices form the backbone and there are six ICX 6450 peripheral devices in two rings. This is a dual ring configuration. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 45 Topology 3 is almost identical to topology 2 except that the "horizontal" substack is not connected to the second ICX 6610 device either by design or because the link is broken. This is still a valid topology. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 46 Topology 4 shows that you can have a mixed stack with only one ICX 6610 device, although this configuration does not provide high availability or resiliency for the stack because there is no standby controller. FIGURE 37 Topology 4: Ring with one backbone device Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 47: Connecting Icx 6610 Devices In The Backbone

    ICX 6450 peripheral devices. The first port in a peripheral trunk on a backbone device and the first port in a stack trunk on a peripheral device must be an odd-numbered port, for example, 1/3/1 or 3/2/1. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 48: Extended Distance Stacking

    Attach the AC power cord to the AC connector on the rear panel. Insert the power cord plug into a 100V-240V outlet. NOTE To turn the system off, simply unplug the power cord or cords. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 49: Icx 6400-Eps1500 Installation

    ICX 6430 or ICX 6450 device. Proprietary DC cables are used to connect any of the three EPS ports of the ICX 6400-EPS1500 to the rear EPS port of an ICX 6430 or ICX 6450 device.

  • Page 50: Features And Benefits

    If an ICX 6430 or ICX 6450 device is not connected to an EPS port, the power will not come up. • Power supplies are hot swappable. The device can be running while the ICX 6430 or ICX 6450 units are connected to the ICX 6400-EPS1500.

  • Page 51: Leds

    FIGURE 41 ICX 6400-EPS1500 rear panel Fans External power sockets 1-3 AC power socket LEDs The following figure shows the location of the LEDs on the ICX 6400-EPS1500. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 52 The cooling fan is operating normally. Amber The cooling fan has failed. FAN 3 Green The cooling fan is operating normally. Amber The cooling fan has failed. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 53: Items Included With The Icx 6400-Eps1500

    Verify that the device is working properly by Verifying proper operation on page 65 section plugging it into a power source and verifying that it passes the self test. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 54: Installation Precautions

    Compare this total with the rating limit for the circuit. The maximum ampere ratings are usually printed on the devices near the input power connectors. DANGER Disconnect the power cord from all power sources to completely remove power from the device. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 55: Preparing The Installation Site

    DANGER Mount the devices you install in a rack as low as possible. Place the heaviest device at the bottom and progressively place lighter devices above. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 56: Desktop Installation

    Remove the rack mounting kit from the shipping carton. The kit contains two L-shaped mounting brackets, six sink-head mounting screws, four rack-mounting screws, and four cage nuts. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 57 Using a Phillips screwdriver, attach the mounting brackets to the sides of the external power supply using six sink-head screws. FIGURE 44 Attaching the mounting brackets for the ICX 6400–EPS1500 Mount the external power supply in a rack using four rack-mounting screws. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 58: Assembling The Wire Saddle For The Eps Cord

    EPS cord from accidentally unplugging and losing connection with the external power receptacle. Assemble the wire saddle on both ends of the EPS cord. Complete the following steps to assemble the wire saddle for the EPS cord. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 59 Installing the device FIGURE 46 Removing the EPS faceplate on the ICX 6430 or ICX 6450 device Screws and faceplate Using a Phillips screwdriver, remove the two screws on the EPS faceplate of the external power receptacle, as illustrated in the figure below.
  • Page 60 Clip the cable tie onto the wire saddle, as illustrated in the figure below. FIGURE 47 Assembling the cable tie and wire saddle Cable tie Wire saddle Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 61 FIGURE 48 Complete assembly of cable tie and wire saddle Wire saddle Open the wire saddle hook and plug the EPS cord into the external power receptacle. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 62: Connecting Devices To The External Power Supply

    (EPS OUT 1, EPS OUT 2, and EPS OUT 3). Repeat Step 1 and Step 2 to connect up to three devices to the external power supply. Refer to the following figure. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 63 Installing the device Connect one end of the AC cord to the AC receptacle on the external power supply, and the other end to a grounded power outlet. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 64 For international use, you may need to change the AC line cord. You must use a line cord set that has been approved for the receptacle type in your country. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 65: Powering On The System

    LEDs for linked ports will come on during the boot process, then all LEDs will go off. Once the boot sequence is complete, LEDs for linked ports will again come on. For more details on specific LED conditions after system startup, refer to, LEDs on page 51. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 66 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 67: Configuring An Icx 6430 Or Icx 6450 Device

    You can access the CLI by attaching a serial cable to the console port. After you assign an IP address, you can access the system through Telnet or Brocade Network Advisor. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 68: Password Assignment

    CONFIG - The configuration level. This level allows you to configure the system IP address and configure switching and routing features. To access the CONFIG mode, you must already be logged in to the Privileged EXEC level. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 69: Assigning Passwords

    Recovery from a lost password requires direct access to the serial port and a system reset. Start a CLI session over the serial interface to the Brocade device. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 70: Ip Address Configuration

    Devices running Layer 2 software NOTE The ICX 6430 device supports only switch code. The ICX 6450 device supports both switch and router code. Use the following procedure to configure an IP address on a device running Layer 2 software.

  • Page 71: Devices Running Layer 3 Software

    Syntax: [no] ip address { ip-addr ip-mask [ secondary ] | ip-addr/mask-bits [ secondary ] } Use the secondary parameter if you have already configured an IP address within the same subnet on the interface. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 72 The num parameter specifies the virtual interface number. You can specify from 1 through the maximum number of virtual interfaces supported on the device. To display the maximum number of virtual interfaces supported on the device, enter the show default values command. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 73: Connecting Network Devices

    Brocade ICX 6430 and ICX 6450 Stackable Switches Technical Specifications on page 91. Cable specifications For information about supported transceivers and cable lengths and types, refer to the product data sheet. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 74: Connecting To Ethernet Or Fast Ethernet Hubs

    1000Base-T ports. In this case, a straight-through cable may work just as well as a crossover cable. For more information about this feature, refer to the Brocade FastIron Security Configuration Guide. FIGURE 51 UTP crossover cable Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 75: Connecting To Workstations, Servers, Or Routers

    For instructions on cabling a fiber-optic transceiver, refer to Cabling a fiber-optic transceiver on page 88. For instructions on cleaning a fiber-optic module, refer to Cleaning the fiber-optic connectors on page 89. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 76: Troubleshooting Network Connections

    Digital optical monitoring NOTE 10 Gbps optical transceivers are not supported on ICX 6430 devices. You can configure your device to monitor optical transceivers in the system, either globally or by specified port. When this feature is enabled, the system monitors the temperature and signal power levels for the optical transceivers in the specified ports. Console messages and syslog messages are sent when optical operating conditions fall below or rise above the SFP and SFP+ manufacturer’s...

  • Page 77: Observing Leds

    Verify that the connection to the other network device has been properly made. • If the other actions do not resolve the problem, try using a different Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 78 Cleaning the fiber-optic connectors page 89. • Verify that the port has not been disabled through a configuration change. • Ensure that the SFP+ in both Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 79 • Dust may have accumulated in the cable connector or port connector. For information about cleaning the connectors, refer Cleaning the fiber-optic Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 80: Tracing A Route

    The CLI displays trace route information for each hop as soon as the information is received. Traceroute requests display all responses to a given TTL. In addition, if there are multiple equal-cost routes to the destination, the Brocade device displays up to two responses by default. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 81: Managing An Icx 6430 Or Icx 6450 Device

    Managing temperature settings The device contains temperature sensors that the software reads based on a configurable device poll time. Except for the ICX 6430-24 model, the device has two automatic speed fan control settings based on the temperature. To protect the device from overheating, the following temperature threshold levels exist: •...

  • Page 82: Displaying Syslog Messages For Temperature

    NOTE For the ICX 6430-24 device, the low and high temperature thresholds (TA and TB) are used only for software settings because the ICX 6430-24 model is a fanless device. There are no fan speed control settings on the ICX 6430-24 device.

  • Page 83: Changing The Temperature Warning Level

    To change the poll time, enter a command similar to the following at the global CONFIG level. Brocade(config)# chassis poll-time 200 Syntax: chassis poll-time value The value variable can be from 0 through 65535 seconds. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 84: Displaying Cpu Usage

    Use the ethernet port-num parameter to remove all MAC addresses for a specified Ethernet port. Use the vlan number parameter to remove all MAC addresses for a specified VLAN. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 85: Hardware Maintenance And Replacement

    Removing a copper or fiber-optic module You can remove a copper or fiber SFP transceiver from a slot while the ICX 6430 or ICX 6450 device is powered on and running. While removing a copper or fiber-optic module, be sure to wear an ESD wrist strap with a plug that can be inserted in the ESD connector on the ICX 6430 or ICX 6450 device.
  • Page 86 Store the copper or fiber-optic module in a safe, static-free place or in an anti-static bag. Install a new copper or fiber-optic module in the port. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 87: Installing A New Copper Or Fiber-Optic Transceiver

    You can install a new fiber-optic transceiver in an SFP or SFP+ slot while the device is powered on and running. While installing a transceiver, wear an ESD wrist strap with a plug that can be inserted in the ESD connector on the ICX 6430 or ICX 6450 device.

  • Page 88: Cabling A Fiber-Optic Transceiver

    Observe the link and active LEDs to determine if the network connections are functioning properly. For more information about the LED indicators, refer to Observing LEDs on page 77. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 89: Cleaning The Fiber-Optic Connectors

    To clean the fiber cable connectors, Brocade recommends using a fiber-optic reel-type cleaner. When not using an SFP connector, make sure to keep the protective covering in place. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 90 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 91: Brocade Icx 6430 And Icx 6450 Stackable Switches Technical Specifications

    Brocade ICX 6430 and ICX 6450 Stackable Switches Technical Specifications This document highlights the features and specifications for the Brocade ICX 6430 and ICX 6450 stackable switches. System specifications System component Description Enclosure 1U; stackable and fanless models; approximately 17 inches wide and 1.7 inches tall...

  • Page 92: Other

    0°C to 45°C (32°F to 113°F) -40°C to 70°C (-40°F to 158°F) Relative humidity (non- 5% to 95% at 40°C (104°F) 0% to 95% at 70°C (158°F) condensing) Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 93: Power Supply Specifications (Per Psu)

    100 - 240 VAC 50/60 Hz 10 A Power consumption (maximum configuration) Maximum: Fully configure all ports with 100% traffic throughput and maximum Power over Ethernet (PoE) load. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 94: Data Port Specifications (Ethernet)

    Data port specifications (Ethernet) NOTE The Brocade ICX 6430 and ICX 6450 stackable switches do not support -48 VDC input power. Model name @100 VAC input @200 VAC input @-48 VDC input Minimum number of Notes power supplies ICX 6430-24 0.9 A...

  • Page 95: Serial Port Specifications (Pinout Rj-45)

    Serial port specifications (protocol) Parameter Value Baud 9600 bps Data bits Parity None Stop bits Flow control None Regulatory compliance (EMC) • FCC Part 15, Subpart B (Class A) Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 96: Regulatory Compliance (Safety)

    SJ/T 11363-2006 Requirements for Concentration Limits for Certain Hazardous Substances in EIPs (China) • SJ/T 11364-2006 Marking for the Control of Pollution Caused by EIPs (China) Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 97: Troubleshooting

    IP address. Also, be sure the port through which you are connecting to the device has not been disabled. If it has not been disabled, then check the network cabling that runs between your remote location and the device. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 98 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 99: Regulatory Statements

    This is Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 100: Canadian Requirements

    This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations, ICES-003 Class A. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. China CC statement Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 101: Europe And Australia (Cispr 22 Class A Warning)

    (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 102 Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 103: Cautions And Danger Notices

    Lassen Sie keine Werkzeuge im Chassis zurück. MISE EN GARDE Ne laissez jamais d'outils à l'intérieur du châssis PRECAUCIÓN No deje nunca herramientas en el interior del chasis. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 104: Electrical Cautions

    PRECAUCIÓN Use un circuito derivado separado para cada cordón de alimentación, con lo que se proporcionará redundancia en caso de que uno de los circuitos falle. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 105: Danger Notices

    Una advertencia de peligro indica condiciones o situaciones que pueden resultar potencialmente letales o extremadamente peligrosas. También habrá etiquetas de seguridad pegadas directamente sobre los productos para advertir de estas condiciones o situaciones. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 106: General Dangers

    Esta marca será su garantía de que el cordón de corriente puede ser utilizado con seguridad con el instrumento. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

  • Page 107: Dangers Related To Equipment Weight

    All fiber-optic interfaces use Class 1 lasers. GEFAHR Alle Glasfaser-Schnittstellen verwenden Laser der Klasse 1. DANGER Toutes les interfaces en fibres optiques utilisent des lasers de classe 1. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...
  • Page 108 Danger Notices PELIGRO Todas las interfaces de fibra óptica utilizan láser de clase 1. Brocade ICX 6430 and ICX 6450 Stackable Switches Hardware Installation Guide Part Number: 53-1003617-03...

This manual is also suitable for:

Icx 6450

Table of Contents
