Exposure Points

reliability. The following precautions should be taken when encapsulating the supply
air plenum in an on-line room:
Manually apply the encapsulant. Spray applications are totally inappropriate in an
■
on-line data center. The spraying process forces the sealant airborne in the supply
airstream, and is more likely to encapsulate cables to the deck.
Use a pigmented encapsulant. The pigmentation makes the encapsulant visible in
■
application, ensuring thorough coverage, and helps in identifying areas that are
damaged or exposed over time.
It must have a high flexibility and low porosity to effectively cover the irregular
■
textures of the subject area, and to minimize moisture migration and water
damage.
The encapsulant must not out-gas any harmful contaminants. Many encapsulants
■
commonly used in industry are highly ammoniated or contain other chemicals
that can be harmful to hardware. It is very unlikely that this out-gassing could
cause immediate, catastrophic failure, but these chemicals will often contribute to
corrosion of contacts, heads or other components.
Effectively encapsulating a subfloor deck in an on-line computer room is a very
sensitive and difficult task, but it can be conducted safely if appropriate procedures
and materials are used. Avoid using the ceiling void as an open supply or return for
the building air system. This area is typically very dirty and difficult to clean. Often
the structural surfaces are coated with fibrous fire-proofing, and the ceiling tiles and
insulation are also subject to shedding. Even before filtration, this is an unnecessary
exposure that can adversely affect environmental conditions in the room. It is also
important that the ceiling void does not become pressurized, as this will force dirty air
into the computer room. Columns or cable chases with penetrations in both the
subfloor and ceiling void can lead to ceiling void pressurization.
Exposure Points
All potential exposure points in the data center should be addressed to minimize
potential influences from outside the controlled zone. Positive pressurization of the
computer rooms will help limit contaminant infiltration, but it is also important to
minimize any breaches in the room perimeter. To ensure the environment is
maintained correctly, the following should be considered:
All doors should fit snugly in their frames.
■
Gaskets and sweeps can be used to address any gaps.
■
Automatic doors should be avoided in areas where they can be accidentally
■
triggered. An alternate means of control would be to remotely locate a door trigger
so that personnel pushing carts can open the doors easily. In highly sensitive areas,
or where the data center is exposed to undesirable conditions, it may be advisable
to design and install personnel traps. Double sets of doors with a buffer between
can help limit direct exposure to outside conditions.
Seal all penetrations between the data center and adjacent areas.
■
Avoid sharing a computer room ceiling or subfloor plenum with loosely controlled
■
adjacent areas.

Filtration

Filtration is an effective means of addressing airborne particulate in a controlled
environment. It is important that all air handlers serving the data center are
