Table 64. Comparator 2 Characteristics - STMicroelectronics STM32L151CCT6 Manual

STM32L151xC STM32L152xC
1. Guaranteed by characterization results, not tested in production.
2. The delay is characterized for 100 mV input step with 10 mV overdrive on the inverting input, the non-
inverting input set to the reference.
3. Comparator consumption only. Internal reference voltage not included.
Symbol
V
DDA
V
IN
t
START
t
d slow
t
d fast
V
offset
dThreshold/
dt
I
COMP2
1. Guaranteed by characterization results, not tested in production.
2. The delay is characterized for 100 mV input step with 10 mV overdrive on the inverting input, the non-
inverting input set to the reference.
3. Comparator consumption only. Internal reference voltage (necessary for comparator operation) is not
included.

Table 64. Comparator 2 characteristics

Parameter
Analog supply voltage
Comparator 2 input voltage range
Comparator startup time
(2)
Propagation delay in slow mode
(2)
Propagation delay in fast mode
Comparator offset error
Threshold voltage temperature
coefficient
(3)
Current consumption
DocID022799 Rev 10
Electrical characteristics
Conditions
-
-
Fast mode
Slow mode
1.65 V ≤ V ≤ 2.7 V
DDA
2.7 V ≤ V ≤ 3.6 V
DDA
1.65 V ≤ V ≤ 2.7 V
DDA
2.7 V ≤ V ≤ 3.6 V
DDA
= 3.3V
V
DDA
= 0 to 50 ° C
T
A
V- =V ,
REFINT
3/4 V ,
REFINT
1/2 V ,
REFINT
1/4 V .
REFINT
Fast mode
Slow mode
(1)
Min Typ Max Unit
1.65 - 3.6 V
0 - V V
DDA
- 15 20
- 20 25
- 1.8 3.5
µs
- 2.5 6
- 0.8 2
- 1.2 4
±4 ±20
- mV
ppm
- 15 30
/°C
- 3.5 5
µA
- 0.5 2
