Installation

2.4.6 Control Wiring

2.4.6.1 Control Terminal Types

Illustration 2.27 shows the removable frequency converter
connectors. Terminal functions and default settings are
2 2
summarized in Table 2.5.
2
I I llustration 2.27 Control Terminal Locations
1 Connector 1: Terminals 12-37
2 Connector 2: Terminals 61-69
3 Connector 3: Terminals 39-55
4 Connector 4: Terminals 1-6
Table 2.4 Legend to Illustration 2.27
•
Connector 1 provides four programmable digital
inputs terminals, two additional digital terminals
programmable as either input or output, a 24 V
DC terminal supply voltage, and a common for
optional customer supplied 24 V DC voltage
•
Connector 2 terminals (+)68 and (-)69 are for an
RS-485 serial communications connection
•
Connector 3 provides two analog inputs, one
analog output, 10 V DC supply voltage, and
commons for the inputs and output
•
Connector 4 is a USB port available for use with
the frequency converter
20
inverter.ru (812) 702-47-50
VLT Refrigeration Drive FC 103 1.1-90 kW Operating Instructions
•
•
See 10.2 General Technical Data for terminal ratings details.
Terminal Parameter
12, 13
3
18
19
32
33
4
27
29
20
1
37
39
42
50
53
54
55
MG16E202 - VLT® is a registered Danfoss trademark
Also provided are two Form C relay outputs that
are in various locations depending upon the
frequency converter configuration and size
Some options available for ordering with the unit
may provide additional terminals. See the manual
provided with the equipment option.
Digital Inputs/Outputs
Default
Setting
- +24 V DC 24 V DC supply
voltage. Maximum
output current is 200
mA total for all 24 V
loads. Useable for
digital inputs and
external transducers.
5-10 [8] Start
5-11 [10] Reversing
5-14 [39] Day/Night
Digital inputs.
Control
5-15 [0] No
operation
5-12 [2] Coast Selectable for either
inverse digital input or
output. Default setting
5-13 [0] No
operation is input.
- Common for digital
inputs and 0 V
potential for 24 V
supply.
- Safe Torque (Optional) Safe input.
Off (STO) Used for STO
Analog Inputs/Outputs
- Common for analog
output
6-50 [100] Output Programmable analog
frequency output. The analog
signal is 0-20 mA or
4-20 mA at a
maximum of 500
- +10 V DC 10 V DC analog
supply voltage. 15 mA
maximum commonly
used for potenti-
ometer or thermistor.
6-1* Reference Analog input.
Selectable for voltage
6-2* Feedback
or current. Switches
A53 and A54 select
mA or V.
- Common for analog
input
Serial Communication
Description
