Specifications
10.1.4 Mains Supply 3x525-690 V AC
F F requency converter
Typical Shaft Output [kW]
Typical Shaft Output [HP]
at 575 V
IP21/NEMA 1
IP55/NEMA 12
Output current
Continuous
(3x525-550 V) [A]
Intermittent
(3x525-550 V) [A]
Continuous
(3x551-690 V) [A]
Intermittent
(3x551-690 V) [A]
Continuous kVA
(550 V AC) [kVA]
Continuous kVA
(575 V AC) [kVA]
Continuous kVA
(690 V AC) [kVA]
Max. cable size
(mains, motor, brake)
2 2)
[mm ]/(AWG)]
Max. input current
Continuous
(3x525-690 V) [A]
Intermittent
(3x525-690 V) [A]
1)
Max. pre-fuses [A]
Environment:
Estimated power loss
at rated max. load [W]
Weight:
IP21 [kg]
IP55 [kg]
4)
Efficiency
1)
For type of fuse see 10.3 Fuse Specifications
2)
American Wire Gauge
3)
Measured using 5 m screened motor cables at rated load and rated frequency
4)
The typical power loss is at normal load conditions and expected to be within 15% (tolerance relates to variety in voltage and cable
conditions).
Values are based on a typical motor efficiency. Lower efficiency motors will also add to the power loss in the frequency converter and
vice versa.
If the switching frequency is raised from nominal the power losses may rise significantly.
LCP and typical control card power consumptions are included. Further options and customer load may add up to 30 W to the losses.
(Though typically only 4 W extra for a fully loaded control card or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be allowed for ( 5%).
5)
Motor and mains cable: 300 MCM/150 mm
6)
A2+A3 may be converted to IP21 using a conversion kit. See also Mechanical mounting and IP21/Type 1 Enclosure kit in the Design
Guide.
7)
B3+4 and C3+4 may be converted to IP21 using a conversion kit. See also Mechanical mounting and IP21/Type 1 Enclosure kit in the
Design Guide.
Table 10.8 Mains Supply 3x525-690 V AC - Normal overload 110% for 1 minute
inverter.ru (812) 702-47-50
VLT Refrigeration Drive FC 103 1.1-90 kW Operating Instructions
P11K P15K P18K
11 15 18.5
10 16.4 20.1
B2 B2 B2
B2 B2 B2
14 19 23
15.4 20.9 25.3
13 18 22
14.3 19.8 24.2
13.3 18.1 21.9
12.9 17.9 21.9
15.5 21.5 26.3
35 (1/0)
15 19.5 24
16.5 21.5 26.4
63 63 63
201 285 335
4)
27 27 27
27 27 27
0.98 0.98 0.98
2
