Warnings and Alarms
N N o. Description
80 Drive Initialized to Default Value
91 Analog input 54 wrong settings
92 NoFlow
93 Dry Pump
94 End of Curve
95 Broken Belt
96 Start Delayed
97 Stop Delayed
98 Clock Fault
203 Missing Motor
204 Locked Rotor
243 Brake IGBT
244 Heatsink temp
245 Heatsink sensor
246 Pwr.card supply
247 Pwr.card temp
248 Illegal PS config
250 New spare parts
251 New Type Code
Table 8.2 Alarm/Warning Code List
(X) Dependent on parameter
1)
Cannot be Auto reset via 14-20 Reset Mode
The warning/alarm information below defines each
warning/alarm condition, provides the probable cause for
the condition, and details a remedy or troubleshooting
procedure.
WARNING 1, 10 Volts low
The control card voltage is below 10 V from terminal 50.
Remove some of the load from terminal 50, as the 10 V
supply is overloaded. Max. 15 mA or minimum 590
This condition can be caused by a short in a connected
potentiometer or improper wiring of the potentiometer.
Troubleshooting
Remove the wiring from terminal 50. If the warning clears,
the problem is with the customer wiring. If the warning
does not clear, replace the control card.
inverter.ru (812) 702-47-50
VLT Refrigeration Drive FC 103 1.1-90 kW Operating Instructions
Warning Alarm/Trip
X
X X
X X
X X
X X
X
X
X
X X
X X
X
X
X
X
X
WARNING/ALARM 2, Live zero error
This warning or alarm only appears if programmed by the
user in 6-01 Live Zero Timeout Function. The signal on one
of the analog inputs is less than 50% of the minimum
value programmed for that input. Broken wiring or faulty
device sending the signal can cause this condition.
Troubleshooting
.
WARNING/ALARM 4, Mains phase loss
A phase is missing on the supply side, or the mains
voltage imbalance is too high. This message also appears
for a fault in the input rectifier on the frequency converter.
Options are programmed at 14-12 Function at Mains
Imbalance.
Troubleshooting
Check the supply voltage and supply currents to the
frequency converter.
MG16E202 - VLT® is a registered Danfoss trademark
Alarm/Trip Lock Parameter Reference
X
22-2* No-Flow Detection
22-2* No-Flow Detection
22-5* End of Curve
22-6* Broken Belt Detection
22-7* Short Cycle Protection
22-7* Short Cycle Protection
0-7* Clock Settings
X
X
X
X
X
X
X
Check connections on all the analog input
terminals. Control card terminals 53 and 54 for
signals, terminal 55 common. MCB 101 terminals
11 and 12 for signals, terminal 10 common. MCB
109 terminals 1, 3, 5 for signals, terminals 2, 4, 6
common).
Check that the frequency converter programming
and switch settings match the analog signal type.
Perform Input Terminal Signal Test.
