3.3.2 Required Initial Frequency Converter
Programming
N N OTE
If the wizard is run, ignore the following.
Frequency converters require basic operational
programming before running for best performance. Basic
3
3
operational programming requires entering motor-
nameplate data for the motor being operated and the
minimum and maximum motor speeds. Enter data in
accordance with the following procedure. Parameter
settings recommended are intended for start up and
checkout purposes. Application settings may vary. See
4 User Interface for detailed instructions on entering data
through the LCP.
Enter data with power ON, but before operating the
frequency converter.
1.
Press [Main Menu] twice on the LCP.
2.
Use the navigation keys to scroll to parameter
group 0-** Operation/Display and press [OK].
Illustration 3.26 Main Menu
3.
Use navigation keys to scroll to parameter group
0-0* Basic Settings and press [OK].
Illustration 3.27 Operation/Display
32
inverter.ru
(812) 702-47-50
VLT Refrigeration Drive FC 103 1.1-90 kW Operating Instructions
1107 RPM
3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
0.0%
0.00A
Operation / Display
0-0
Basic Settings
*
0-1
Set-up Opperations
*
0-2
LCP Display
*
0-3
LCP Custom Readout
*
MG16E202 - VLT® is a registered Danfoss trademark
4.
Use navigation keys to scroll to 0-03 Regional
Settings and press [OK].
Illustration 3.28 Basic Settings
5.
Use navigation keys to select [0] International or
[1] North America as appropriate and press [OK].
(This changes the default settings for a number
of basic parameters. See 5.4 International/North
American Default Parameter Settings for a
complete list.)
6.
Press [Quick Menu] on the LCP.
7.
Use the navigation keys to scroll to parameter
group Q2 Quick Setup and press [OK].
1 (1)
Illustration 3.29 Quick Menus
8.
Select language and press [OK].
9.
A jumper wire should be in place between
control terminals 12 and 27. If this is the case,
leave 5-12 Terminal 27 Digital Input at factory
1(1)
default. Otherwise select No Operation. For
0-
**
frequency converters with an optional Danfoss
bypass, no jumper wire is required.
10.
3-02 Minimum Reference
11.
3-03 Maximum Reference
12.
3-41 Ramp 1 Ramp Up Time
13.
3-42 Ramp 1 Ramp Down Time
14.
3-13 Reference Site. Linked to Hand/Auto* Local
Remote.
0.0%
0.00A
Basic Settings
0-03 Regional Settings
[0] International
13.7%
13.0A
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q5 Changes Made
Q6 Loggings
1(1)
0-0
*
1(1)
