Installation
2 2
Illustration 2.35 Jumper between Terminal 12/13 (24 V) and 37
1
Illustration 2.36 Installation to Achieve a Stopping Category 0 (EN 60204-1) with Safety Cat. 3 (EN 954-1) / PL "d" (ISO 13849-1).
1 Safety device Cat. 3 (circuit interrupt device, possibly
with release input)
2 Door contact
3 Contactor (Coast)
4 Frequency converter
5 Mains
6 Control board
Table 2.9 Legend to Illustration 2.36
24
inverter.ru (812) 702-47-50
VLT Refrigeration Drive FC 103 1.1-90 kW Operating Instructions
3
2
11
10
7 Inverter
8 Motor
9 5 V DC
10 Safe channel
11 Short-circuit protected cable (if not inside installation cabinet)
MG16E202 - VLT® is a registered Danfoss trademark
4
12
37
9
5
6
7
8
M
