EVER UPS POWERLINE RT 6000 / 10000 series instruction manual
CAUTION! First connect the battery module to a grounding strip using a
cable designed for the battery module.
B. Installation of the battery module in the 10 kVA UPS model:
Fig. 17: Connecting the battery module cable to the UPS battery connector.

TOWER VERSION UPS INSTALLATION

Fig. 18 shows the installation of the POWERLINE RT UPS in the Tower version. To
keep safety (stability), install support elements on both sides of the UPS unit (it will
secure the device from falling).
a)
Fig. 18: Installation of the UPS in tower version: a) POWERLINE RT 6000, b) POWERLINE RT 10000.
29
www.ever.eu Pomoc Techniczna, tel.: +48 61 6500 400
b)
