EVER UPS POWERLINE RT 6000 / 10000 series instruction manual

Installation of the UPS unit and the battery module in a rack

1. Open the front panel of the UPS unit and place it on the UPS unit.
a)
Fig. 9: Opening the front panel: a) POWERLINE RT 6000, b) POWERLINE RT 10000.
2. Remove the cover of internal batteries (fig. 10):
a)
Fig. 10: Removing battery cover: a) POWERLINE RT 6000, b) POWERLINE RT 10000.
3. Slide and take out the battery set using plastic handles (fig. 11)
a)
Fig. 11: Removing battery pack: a) POWERLINE RT 6000, b) POWERLINE RT 10000.
25
www.ever.eu
b)
Pomoc Techniczna, tel.: +48 61 6500 400
b)
b)
2017-01-05 13:16
