EVER UPS POWERLINE RT 6000 / 10000 series instruction manual

HOW IT WORKS

Fig. 6 shows POWERLINE RT front panel elements (both UPS models have identical
LCD displays and control buttons).
Fig. 6: View of the front panel elements in POWERLINE RT UPS.
1. LCD display.
2. Start / shut down button
3. Scroll button
4. Scroll button
5. Selection button
The UPS features a 4-button control panel and an LCD display with a dual colour
backlight. In a normal situation a white text is shown on a blue background. In case
of a critical alarm text colour changes to dark amber and the background colour
changes to red.
Figure 7 shows the display and the control panel, as well as the description of its
elements. Table 1 presents the description of the keys of the control panel and Table
2 presents the description of information icons of the LCD display.
