EVER UPS POWERLINE RT 6000 / 10000 series instruction manual
B) UPS status menu
The primary UPS status menu window consists of the same elements as the default
UPS functional state summary menu. To enter the next UPS status menu window
press in the UPS status menu.
To go back to the previous main menu window press for at least 1 s.
Fig. 25 shows detailed information on the structure of the UPS status menu.
C) Event log Menu
To enter the next Event log menu window, press in the Event log menu.
All past events, alarms and failures are saved here. A log entry consists of the event
code and working time of the UPS unit from the moment of the occurrence of the
event (fig. 26). To view subsequent events, one by one, press and hold the or the
button for less than 1 s.
The device can save a maximum of 50 events. If the number of events is higher than
50, the newest one overwrites the oldest one.
To go back to the previous main menu window, press for at least 1 s.
