EVER UPS POWERLINE RT 6000 / 10000 series instruction manual
4. Few seconds later the UPS unit will enter battery operation mode. If power from
the mains returns, the UPS unit will switch to mains mode, continuously supplying
power to the receivers .
C) Turning off the UPS unit (powered from the mains)
1. Switch off the inverter of the UPS unit by holding the
seconds. The UPS unit will enter the bypass mode.
2. After finishing the above operation, the UPS unit is still under voltage. To switch
off powering of the UPS unit, disconnect the mains power supply. Few second
later the LCD display will switch off and there will be no voltage at the output
terminals of the UPS unit.
D) Turning off the UPS unit (operating in the battery mode, not powered
from the mains)
1. Switch off the inverter of the UPS unit by holding the
seconds. The UPS unit will immediately finish powering (there will be no voltage
at the output of the UPS unit).
2. Approximately 15 s second later the LCD display will switch off.
CONTROL PANEL AND LCD DISPLAY FUNCTIONS ‑ MENU STRUCTURE
The LCD display shows a lot of useful information concerning the current functional
state of the UPS unit, detailed measurements, past events or identification data of
the device. Additionally using function buttons of the control panel, the settings of the
UPS unit can be adjusted to specific user's requirements. Moreover, it allows the
user to optimize the operation of the UPS unit.
A) Main menu
To obtain detailed information concerning alarms, the power line status or the
battery, press and hold the
functional state screen of the UPS unit.
To navigate to the main menu in the tree from, press and hold the
than 1 s in the default functional state screen of the UPS unit.
The structure of the main menu (block diagram, fig. 25) consists of 6 branches
(menus): UPS status, Event log, Measurements, Control, Identification and Settings.
39
www.ever.eu
or the
Pomoc Techniczna, tel.: +48 61 6500 400
button for more than 3
button for more than 3
button for less than 1 s in the default
button for less
