ITEM # PART #
1 79-844-00
2 88-818-06
3 -
4 79-840-20
5 62-204-00
6 72-501-36
7 72-501-37
8 88-838-06
9 73-004-20
10 01-110-35
11 97-211-20
12 88-838-06
13 88-817-09
14 61-838-41
15 88-088-62
16 88-099-91
17 61-838-42
18 88-049-80
18a 88-048-62
19 88-080-11
20 88-088-62
21 88-089-80
Not shown 78-302-50
Not shown 75-224-10
Speed Control Panel
DESCRIPTION
Circuit breaker
#8 x 1/2 Pan head screw, type B thread
-
Circuit breaker
PMC speed control
ISO Solenoid (SPST), includes #15, 16 and 18
Forward or Reverse solenoid (SPDT, includes #15, 16 and 18
#14 x 1/2 Pan head screw, type D thread
Horn
Mounting panel
14NC U-nut
#14 x 1/2 Pan head screw, type D thread
#8 x 3/4 Phillips head sheet metal screw
Buss bar
5/16 Split lock washer
Hex thin pattern nut
Buss bar
10-32 Hex nut
#10 Split lock washer
5/16NC x 1 Hex bolt
5/16 Split lock washer
5/16NC Hex nut, stainless steel
ISO resistor assembly
Jumper with diode
Parts Page 23
Ilustrated Parts
QTY
1
2
-
1
1
1
2
8
1
1
4
2
2
2
10
10
2
6
6
4
4
4
1
1
