CAPA110/111 AMD Embedded G-Series Processor Capa Board with LVDS
1.2

Specifications

CPU
AMD G-Series APU dual core T56N 1.65 GHz
AMD G-Series APU dual core T40E 1.0 GHz
AMD G-Series APU single core T40R 1.0 GHz
System Chipset
AMD A50M
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS
16Mbit SPI Flash, DMI, Plug and Play
RPL/PXE Ethernet Boot ROM
System Memory
One 204-pin unbuffered DDR3 SO-DIMM socket
Maximum to 4GB DDR3 1066 MHz memory for T40E/T40R
Maximum to 4GB DDR3 1333 MHz memory for T56N
Onboard Multi I/O
Controller: Nuvoton W83627UHG
Serial Ports: One port for RS-232/422/485 and three ports for RS-232
SATA
Two SATA-600 connectors
CompactFlash™ Socket
One CompactFlash™ Type II Socket
USB Interface
Six USB ports with fuse protection and complies with USB Spec. Rev. 2.0
Display
A slim type 15-pin D-Sub connector as VGA connector
One 40-pin connector for 18/24-bit single/dual channel LVDS
One Display Port (CAPA110 only)
Watchdog Timer
1~255 seconds or minutes; up to 255 levels
Ethernet
Two ports with Realtek RTL8111E for Gigabit/Fast Ethernet
Audio
HD audio compliant (with speaker/line-out & line/MIC-in) with Realtek ALC662
Speaker/line-out & MIC-in & Line-in via Box Header connector
Expansion Interface
One PCI-Express Mini Card socket which complies with PCI-Express Mini Card spec
v1.2
Power Management
ACPI(Advanced Configuration and Power Interface)
Form Factor
3.5" form factor
2
Note: All specifications and images are subject to change without notice.
