CAPA110/111 AMD Embedded G-Series Processor Capa Board with LVDS
CAPA11
The CAPA110/111, a Capa board, supports AMD G-Series APU T56N/T40E/T40R. The board
integrates the Fusion Controller Hub A50M and delivers outstanding system performance
through high-bandwidth interfaces, multiple I/O functions for interactive applications and
various embedded computing solutions.
There is one 204-pin unbuffered SO-DIMM socket for single channel DDR3-1066/1333 MHz
memory (only T56N can be up to DDR3-1333), maximum memory capacity up to 4GB. It also
features two Gigabit/Fast Ethernet ports, two serial ATA channels for total two Serial ATA hard
drives at maximum transfer rate up to 600MB/sec, six USB 2.0 high speed compliant, and
built-in HD audio codec that can achieve the best stability and reliability for industrial
applications. Additionally, it provides you with unique embedded features, such as 4 serial
ports and 3.5" form factor that applies an extensive array of PC peripherals.
1.1

Features

AMD G-Series APU dual core T56N (1.65 GHz), T40E (1.0GHz) and single core T40R
(1.0GHz)
AMD Fusion Controller Hub A50M chipset
1 DDR3 SO-DIMM supports up to 4 GB memory capacity
6 USB 2.0 ports
4 COM ports
+12V only DC-in supported
®
DirectX 11 support
Introduction
Chapter 1
Introduction
CAPA111
