2. UPGRADING THE FIRMWARE

The version of your GL200/A's firmware can be upgraded by rewriting the flash ROM on the pertinent circuit
boards. You can upgrade the firmware by loading the update program to a USB memory device.

2.1 How to Upgrade the GL200/A Flash ROM from the USB memory device

Preparations for the upgrade
Firmware :Mxxxa001.G20 ← Main Program file for GL200/A
:Mxxxa002.G20 ← Main Program file for GL200/A
Note:
The former firmware version of 2.00 are for the GL200.
The firmware version from 2.00 is for the GL200A.
Do not install firmware of the GL200A to the GL200.
(1) Connect the AC adapter for the GL200/A.
(2) Turn on the GL200/A.
(3) Copy the two main program files to a USB memory device from the computer.
How to upgrade
(1) Insert the USB memory device containing the main upgrade program into the GL200/A's USB port.
(2) Turn on the GL200/A to automatically execute the upgrade program.
(3) Wait until the display shown below appears or until the beeper sound stops.
Note:
Don't turn off the GL200 until this process is finished.
GL200
The following message will appear on the GL200/A display in yellow characters when the upgrade is
complete. Also the beeper will sound for 5 seconds.
"Please Turn Off the Power.
(4) Turn off the power to the GL200/A when the above message is displayed or when the beeper sound
stops.
(5) Delete the two main program files from the USB memory device.
This is to avoid upgrading the firmware by mistake.
GL200-UM-251-9370
I have locked up."
2-1
