SIMATIC Box PC 620 Expansions
Caution
!
The electronic components of the printed circuit boards are extremely sensitive to
electrostatic discharge. Certain precautionary measures are therefore necessary
when handling such components. These measures are explained in the guidelines
for handling electrostatically sensitive devices at the end of this manual.
Installing the SO DIMM Cards
To plug in expansion submodules, proceed as follows:
1. Open the unit as described in Section 5.1.
2. Plug the cards into the slots. Note the safety recess on the connector side of
the SO DIMM card.
3. Push the card down applying light pressure until it locks into place.
4. Close the unit.
Caution
!
Risk of damage!
Make sure that the cards sit securely in the slots, otherwise they can fall out and
be damaged.
Installation
The memory configuration is detected automatically. When you switch on the unit,
the distribution of base and extended memory is displayed on the screen.
5-10
SIMATIC Box PC 620 Manual
C79000-G7076-C639-04
