SIMATIC
Box PC 620
Getting Started
Edition 04/2003
First Steps in Commissioning
Valid for devices with the order number 6ES7647-5...

Advertisement

Table of Contents

   Also See for Siemens SIMATIC Box PC 620

   Summary of Contents for Siemens SIMATIC Box PC 620

  • Page 1 SIMATIC Box PC 620 Getting Started Edition 04/2003 First Steps in Commissioning Valid for devices with the order number 6ES7647-5...
  • Page 2 Trademarks SIMATICR, SIMATIC HMIR and SIMATIC NETR are registered trademarks of Siemens AG. Third parties using for their own purposes any other names in this document which refer to trademarks might in- fringe upon the rights of the trademark owners.
  • Page 3: Table Of Contents

    This Getting Started offers you step by step instructions on how to install and start the Box PC 620. Unpacking the Box PC 620 ..........Installing the Box PC 620 .
  • Page 4: Installing The Box Pc 620

    Recording the Serial Number and the Ethernet address 6. Enter the serial number and the Ethernet address of your PC in the table below. You can find the serial number on the type label attached to the rear of the device. The Ethernet address can be found in the BIOS setup settings in the main menu under the ’Hardware Options’...
  • Page 5 Depending on the configuration of the device, two mounting brackets are included in the scope of delivery. You can attach these to the housing with 6 screws (M3x6). M4 thread, max. depth of engagement 5 mm M3 thread, max. depth of engagement 5 mm Equipotential grounding connection Instructions for wall and ceiling mounting To install the Box PC 620 at a concrete wall or ceiling proceed as follows:...
  • Page 6 Dimension Drawings for Fitting in Control Panel with Installation Angle (Device without CD ROM Drive) 297.2 80.1 11.2 Getting Started Box PC 620 A5E00131477-03...
  • Page 7 Dimension Drawings for Fitting in Control Panel (Device with CD ROM Drive) 297.2 99.1 Getting Started Box PC 620 A5E00131477-03...
  • Page 8 Dimension Drawings for Fitting in Control Panel without Installation Angle 297.2 80.1 11.2 Getting Started Box PC 620 A5E00131477-03...
  • Page 9 Permissible Fitting Positions of the PC to UL1950/EN60950/CSA22.2 No. 950 An inclined position of + 20_ is allowed in each of the permissible fitting positions. Position 1 (Preferred Position) Position 2 Position 3 (Desktop) Position 4 (Ceiling) *) *) not permissible for installed CD ROM, CD RW/DVD Drive Getting Started Box PC 620 A5E00131477-03...
  • Page 10 Additional Permissible Fitting Positions of the PC to UL508/CSA 22.2 No. 142 An inclined position of $15_ is allowed in each of the permissible fitting positions. An external fire protection housing is not necessary. Position 6 Position 5 (Port Side Down) (Fan Side Down) *) not permissible for installed Floppy disk, CD ROM, CD RW/DVD Drive Caution...
  • Page 11: Hardware Components Of The Box Pc 620

    Hardware Components of the Box PC 620 Port Side View Mouse PS/2 socket for connecting a PS/2 mouse. COM1 V.24 /MODEM /AG The COM 1 (TTY) port is used to connect, for example, S5 automation units (AG). The supplied adapter can be used to convert the port into a 25-pole standard V.24 port for connecting serial port devices such as modem, mouse or printer.
  • Page 12 10 USB 2 Universal Serial Bus connectors. You can use the USB port to connect external devices, for example, CD drives, printers, modems as well as mouse and keyboard. Older operating systems do not support this port. 11 VGA You can connect an external VGA monitor to this connector. 12 LPT1 The parallel port connection for devices with parallel port (for example, printer) 13 Keyboard...
  • Page 13 Front Ports The front ports are located behind the cover below the floppy disk drive. They are used for connection of the following front elements: • I/O port for the connection of front components • LVDS display port Reset Button The reset button can be actuated with a pointed object (e.g.
  • Page 14: Connection To The Power Supply Unit

    Certificate of Authenticity with Product Key You need the Microsoft Windows “Product Key” on the “Certificate of Authenticity” if you reinstall software. Connection to the Power Supply Unit Warning The Box PC 620 with AC power supply is equipped with a safety-tested mains cable and may only be connected to a grounded grounding outlet.
  • Page 15: Powering Up The Box Pc 620

    Powering Up the Box PC 620 The operating system supplied with the Box PC 620 is preinstalled on the hard disk. When powering up the device you have to distinguish between the following: • Initial start to set up the PCs software and a •...
  • Page 16: Reinstallation Of The Software

    Reinstallation of the Software In case of software errors reinstall your software using the Recovery CD, the Documentation and Drivers CD and the Restore CD. Recovery CD: contains the tools for installing the hard disk and the operating systems. Documentation and Drivers CD: contains the documentation and the hardware drivers. Restore CD: contains an Image file with the original delivery software.
  • Page 17: Further Support And Sales Information

    Enter <ALT> <9><2> for < \> Further Support and Sales Information If you have further questions on how to use the Box PC 620, please contact your Siemens representative or the SIMATIC Hotline: • You can obtain general up-to-date information in the Internet under http://www.siemens.com/simatic-pc...
  • Page 18 Technical Support 24 hours a day, 365 days a year Phone: +49 (0) 180 5050-222 Fax: +49 (0) 180 5050-223 E-Mail: adsupport@ siemens.com GMT: +1:00 Europe / Africa (Nuernberg) United States (Johnson City) Asia / Australia (Beijing) Authorization Technical Support and...
  • Page 19: Certificates, Directives And Declarations

    “Low-Voltage Directive.” Conformance with this standard has been verified according to EN 60950. Declaration of Conformity The EU declarations of conformity and the relevant documentation are held at the disposal of the competent authorities at the address below: Siemens Aktiengesellschaft Bereich Automation and Drives A&D AS RD4 Postfach 1963...
  • Page 20 Observing the Installation Guidelines The installation guidelines and safety instructions specified in this documentation or the electronic manual must be observed during startup and operation. Connecting Peripherals The requirements regarding noise immunity (EN50082-2:1995) are met when you connect a peripheral suitable for an industrial environment. Peripheral devices are only be connected via shielded cables.
  • Page 21 Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 22 Siemens AG Organization Group Automation and Drives Getting Started Box PC 620 Division Systems Engineering E Siemens AG 2002 2003 A5E00131477-03 Postfach 2355, D 90766 Fuerth Subject to technical change. Siemens Aktiengesellschaft A5E00131477 03 Printed in the Fed. Rep. of Germany...
